Product Summary
The AO4600 is a field effect transistor which uses advanced trench technology to provide excellent RDS(ON) and low gate charge. The complementary MOSFETs form a high-speed power inverter, suitable for a multitude of applications.
Parametrics
AO4600 absolute maximum ratings: (1)Drain-Source Voltage: +30/-30V; (2)Gate-Source Voltage: ±12V(Ta=25℃); (3)Continuous Drain: 6.9V(Ta=70℃); (4)Current A: 5.8A; (5)Power dissipation: 2W(Ta=25℃), 1.44W(Ta=70℃); (6)Junction and Storage Temperature Range: -55 to 150℃.
Features
AO4600 features: (1)n-channel: VDS (V) = 30V, ID = 6.9A (VGS = 10V), Rds< 27mΩ, < 32mΩ, < 50mΩ; (2)p-channel: VDS (V) =- 30V, ID = -5A (VGS = 10V), Rds< 49mΩ, < 64mΩ, < 120mΩ.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 AO4600 |
Other |
|
Data Sheet |
Negotiable |
|
||||
