Product Summary

The AD8034ARTZ is a Low cost FastFET Op Amp. The device is a voltage feedback amplifier with FET inputs, offering ease of use and excellent performance. The AD8034ARTZ is a dual amplifier. The FastFET op amp in ADI’s proprietary XFCB process offer significant performance improvements over other low cost FET amps, such as low noise (11 nV/√Hz and 0.6 fA/√Hz) and high speed (80 MHz bandwidth and 80 V/μs slew rate). The applications of the AD8034ARTZ include Instrumentation, Filters, Level Shifting, Buffering.

Parametrics

AD8034ARTZ absolute maximum ratings: (1)Supply Voltage: 26.4 V; (2)Common-Mode Input Voltage: 26.4 V; (3)Differential Input Voltage: 1.4 V; (4)Storage Temperature: -65℃ to +125℃; (5)Operating Temperature Range: -40℃ to +85℃; (6)Lead Temperature Range (Soldering 10 sec): 300℃.

Features

AD8034ARTZ features: (1)FET Input Amplifier, 1 pA Typical Input Bias Current; (2)Very Low Cost; (3)High Speed, 80 MHz, –3 dB Bandwidth (G = +1); 80 V/s Slew Rate (G = +2); (4)Low Noise, 11 nV/√Hz (f = 100 kHz); 0.6 fA/√Hz (f = 100 kHz); (5)Wide Supply Voltage Range, 5 V to 24 V; (6)Low Offset Voltage, 1 mV Typical; (7)Single-Supply and Rail-to-Rail Output; (8)High Common-Mode Rejection Ratio –100 dB; (9)Low Power, 3.3 mA/Amplifier Typical Supply Current; (10)No Phase Reversal; (11)Small Packaging, SOIC-8, SOT-23-8, and SC70.

Diagrams

AD8034ARTZ block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
AD8034ARTZ-R2
AD8034ARTZ-R2

Analog Devices Inc

IC OPAMP FET-IN DUAL VFB SOT23-8

Data Sheet

1-250: $1.74
AD8034ARTZ-REEL
AD8034ARTZ-REEL


IC OPAMP VF R-R DUAL LN SOT23-8

Data Sheet

0-10000: $1.16
AD8034ARTZ-REEL7
AD8034ARTZ-REEL7


IC OPAMP VF R-R DUAL LN SOT23-8

Data Sheet

0-1: $2.50
1-10: $2.24
10-25: $2.02
25-100: $1.83
100-250: $1.66
250-500: $1.49
500-1000: $1.25
