Product Summary

The STP75NF75 is the N-channel 75V power MOSFET which realized with STMicroelectronics unique STripFET process. It has specifically been designed to minimize input capacitance and gate charge. It is therefore suitable as primary switch in advanced highefficiency, high-frequency isolated DC-DC converters for Telecom and Computer applications. The STP75NF75 is also intended for any applications with low gate drive requirements.

Parametrics

STP75NF75 absolute maximum ratings: (1)Drain-source voltage (VGS = 0): 75 V; (2)Drain-gate voltage (RGS = 20KΩ): 75 V; (3)Gate-source voltage: ± 20 V; (4)Drain current (continuous) at TC = 25℃: 80 A; (5)Drain current (continuous) at TC=100℃: 70 A; (6)Drain current (pulsed): 320 A; (7)Total dissipation at TC = 25℃: 300, 45 W; (8)Operating junction temperature: -55 to 175℃; (9)Storage temperature: -55 to 175 ℃.

Features

STP75NF75 features: (1)Exceptional dv/dt capability; (2)100% avalanche tested; (3)Current limited by package; (4)Switching application.

Diagrams

STP75NF75 test circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
STP75NF75
STP75NF75

STMicroelectronics

MOSFET N-Ch 75 Volt 80 Amp

Data Sheet

0-1: $1.37
1-10: $1.16
10-100: $0.98
100-250: $0.87
STP75NF75FP
STP75NF75FP

STMicroelectronics

MOSFET N-Ch, 75V-0.0095ohms 80A

Data Sheet

0-620: $1.22
620-1000: $1.04
1000-2000: $1.00
2000-5000: $0.95
STP75NF75L
STP75NF75L

STMicroelectronics

MOSFET N-Ch 75 Volt 75 Amp

Data Sheet

Negotiable
STP75NF75-M
STP75NF75-M

Other


Data Sheet

Negotiable
